Stable Diffusion v3 と OpenVINO による画像生成#

%pip install -q "git+https://github.com/initml/diffusers.git@clement/feature/flash_sd3" "gradio>=4.19" "torch>=2.1" "transformers" "nncf>=2.11.0" "opencv-python" "pillow" "peft>=0.7.0" --extra-index-url https://download.pytorch.org/whl/cpu
%pip install -qU --pre "openvino" --extra-index-url https://storage.openvinotoolkit.org/simple/wheels/nightly

# 次の行のコメントを解除して huggingfacehub にログインし、事前トレーニング済みモデルにアクセスします

# from huggingface_hub import notebook_login, whoami

# try:
#     whoami()
#     print('Authorization token already provided')
# except OSError:
#     notebook_login()

import ipywidgets as widgets

use_flash_lora = widgets.Checkbox(
    value=True,
    description="Use flash SD3",
    disabled=False,
)

load_t5 = widgets.Checkbox(
    value=False,
    description="Use t5 text encoder",
    disabled=False,
)

pt_pipeline_options = widgets.VBox([use_flash_lora, load_t5])
display(pt_pipeline_options)

from pathlib import Path
import torch
from diffusers import StableDiffusion3Pipeline, SD3Transformer2DModel
from peft import PeftModel

MODEL_DIR = Path("stable-diffusion-3")
MODEL_DIR.mkdir(exist_ok=True)

TRANSFORMER_PATH = MODEL_DIR / "transformer.xml"
VAE_DECODER_PATH = MODEL_DIR / "vae_decoder.xml"
TEXT_ENCODER_PATH = MODEL_DIR / "text_encoder.xml"
TEXT_ENCODER_2_PATH = MODEL_DIR / "text_encoder_2.xml"
TEXT_ENCODER_3_PATH = MODEL_DIR / "text_encoder_3.xml"

conversion_statuses = [TRANSFORMER_PATH.exists(), VAE_DECODER_PATH.exists(), TEXT_ENCODER_PATH.exists(), TEXT_ENCODER_2_PATH.exists()]

if load_t5.value:
    conversion_statuses.append(TEXT_ENCODER_3_PATH.exists())

requires_conversion = not all(conversion_statuses)

transformer, vae, text_encoder, text_encoder_2, text_encoder_3 = None, None, None, None, None

def get_pipeline_components():
    pipe_kwargs = {}
    if use_flash_lora.value:
        # LoRA をロード
        transformer = SD3Transformer2DModel.from_pretrained(
            "stabilityai/stable-diffusion-3-medium-diffusers",
            subfolder="transformer",
        )
        transformer = PeftModel.from_pretrained(transformer, "jasperai/flash-sd3")
        pipe_kwargs["transformer"] = transformer
    if not load_t5.value:
        pipe_kwargs.update({"text_encoder_3": None, "tokenizer_3": None})
    pipe = StableDiffusion3Pipeline.from_pretrained("stabilityai/stable-diffusion-3-medium-diffusers", **pipe_kwargs)
    pipe.tokenizer.save_pretrained(MODEL_DIR / "tokenizer")
    pipe.tokenizer_2.save_pretrained(MODEL_DIR / "tokenizer_2")
    if load_t5.value:
        pipe.tokenizer_3.save_pretrained(MODEL_DIR / "tokenizer_3") pipe.scheduler.save_pretrained(MODEL_DIR / "scheduler")
    transformer, vae, text_encoder, text_encoder_2, text_encoder_3 = None, None, None, None, None
    if not TRANSFORMER_PATH.exists():
        transformer = pipe.transformer
        transformer.eval()
    if not VAE_DECODER_PATH.exists():
        vae = pipe.vae
        vae.eval()
    if not TEXT_ENCODER_PATH.exists():
        text_encoder = pipe.text_encoder
        text_encoder.eval()
    if not TEXT_ENCODER_2_PATH.exists():
        text_encoder_2 = pipe.text_encoder_2
        text_encoder_2.eval()
    if not TEXT_ENCODER_3_PATH.exists() and load_t5.value:
        text_encoder_3 = pipe.text_encoder_3
        text_encoder_3.eval()
    return transformer, vae, text_encoder, text_encoder_2, text_encoder_3

if requires_conversion:
    transformer, vae, text_encoder, text_encoder_2, text_encoder_3 = get_pipeline_components()

import inspect
from typing import Callable, Dict, List, Optional, Union

import torch
 from transformers import (
    CLIPTextModelWithProjection,
    CLIPTokenizer,
    T5EncoderModel,
    T5TokenizerFast,
)

from diffusers.image_processor import VaeImageProcessor
from diffusers.models.autoencoders import AutoencoderKL
from diffusers.schedulers import FlowMatchEulerDiscreteScheduler
from diffusers.utils import (
    logging,
)
from diffusers.utils.torch_utils import randn_tensor
from diffusers.pipelines.pipeline_utils import DiffusionPipeline
from diffusers.pipelines.stable_diffusion_3.pipeline_output import StableDiffusion3PipelineOutput

logger = logging.get_logger(__name__) # pylint: disable=invalid-name

# diffusers.pipelines.stable_diffusion.pipeline_stable_diffusion.retrieve_timesteps からコピー
def retrieve_timesteps(
    scheduler,
    num_inference_steps: Optional[int] = None,
    device: Optional[Union[str, torch.device]] = None,
    timesteps: Optional[List[int]] = None,
    sigmas: Optional[List[float]] = None,
    **kwargs,
):
    """
    Calls the scheduler's `set_timesteps` method and retrieves timesteps from the scheduler after the call.Handles
    custom timesteps. Any kwargs will be supplied to `scheduler.set_timesteps`.
    Args:
        scheduler (`SchedulerMixin`):
            The scheduler to get timesteps from.
        num_inference_steps (`int`):
            The number of diffusion steps used when generating samples with a pre-trained model.If used, `timesteps`
            must be `None`.
        device (`str` or `torch.device`, *optional*):
            The device to which the timesteps should be moved to.If `None`, the timesteps are not moved.
        timesteps (`List[int]`, *optional*):
            Custom timesteps used to override the timestep spacing strategy of the scheduler.If `timesteps` is passed,
            `num_inference_steps` and `sigmas` must be `None`.
        sigmas (`List[float]`, *optional*):
            Custom sigmas used to override the timestep spacing strategy of the scheduler.If `sigmas` is passed,
            `num_inference_steps` and `timesteps` must be `None`.
        Returns:
            `Tuple[torch.Tensor, int]`: A tuple where the first element is the timestep schedule from the scheduler and the
        second element is the number of inference steps.
    """
    if timesteps is not None and sigmas is not None:
        raise ValueError("Only one of `timesteps` or `sigmas` can be passed.Please choose one to set custom values")
    if timesteps is not None:
        accepts_timesteps = "timesteps" in set(inspect.signature(scheduler.set_timesteps).parameters.keys())
        if not accepts_timesteps:
            raise ValueError(
                f"The current scheduler class {scheduler.__class__}'s `set_timesteps` does not support custom"
                f" timestep schedules. Please check whether you are using the correct scheduler."
            )
        scheduler.set_timesteps(timesteps=timesteps, device=device, **kwargs)
        timesteps = scheduler.timesteps
        num_inference_steps = len(timesteps)
    elif sigmas is not None:
        accept_sigmas = "sigmas" in set(inspect.signature(scheduler.set_timesteps).parameters.keys())
        if not accept_sigmas:
            raise ValueError(
                f"The current scheduler class {scheduler.__class__}'s `set_timesteps` does not support custom"
                f" sigmas schedules. Please check whether you are using the correct scheduler."             )
        scheduler.set_timesteps(sigmas=sigmas, device=device, **kwargs)
        timesteps = scheduler.timesteps
        num_inference_steps = len(timesteps)
    else:
        scheduler.set_timesteps(num_inference_steps, device=device, **kwargs)
        timesteps = scheduler.timesteps
    return timesteps, num_inference_steps

class OVStableDiffusion3Pipeline(DiffusionPipeline):
    r"""
    Args:
        transformer ([`SD3Transformer2DModel`]):
            Conditional Transformer (MMDiT) architecture to denoise the encoded image latents.
        scheduler ([`FlowMatchEulerDiscreteScheduler`]):
            A scheduler to be used in combination with `transformer` to denoise the encoded image latents.
        vae ([`AutoencoderKL`]):
            Variational Auto-Encoder (VAE) Model to encode and decode images to and from latent representations.
        text_encoder ([`CLIPTextModelWithProjection`]):
            [CLIP](https://huggingface.co/docs/transformers/model_doc/clip#transformers.CLIPTextModelWithProjection),
            specifically the [clip-vit-large-patch14](https://huggingface.co/openai/clip-vit-large-patch14) variant,
            with an additional added projection layer that is initialized with a diagonal matrix with the `hidden_size`
            as its dimension.
        text_encoder_2 ([`CLIPTextModelWithProjection`]):
            [CLIP](https://huggingface.co/docs/transformers/model_doc/clip#transformers.CLIPTextModelWithProjection),
            specifically the
            [laion/CLIP-ViT-bigG-14-laion2B-39B-b160k](https://huggingface.co/laion/CLIP-ViT-bigG-14-laion2B-39B-b160k)
            variant.
        text_encoder_3 ([`T5EncoderModel`]): Frozen text-encoder. Stable Diffusion 3 uses
            [T5](https://huggingface.co/docs/transformers/model_doc/t5#transformers.T5EncoderModel), specifically the
            [t5-v1_1-xxl](https://huggingface.co/google/t5-v1_1-xxl) variant.
        tokenizer (`CLIPTokenizer`):
            Tokenizer of class
            [CLIPTokenizer](https://huggingface.co/docs/transformers/v4.21.0/en/model_doc/clip#transformers.CLIPTokenizer).
        tokenizer_2 (`CLIPTokenizer`):
            Second Tokenizer of class
            [CLIPTokenizer](https://huggingface.co/docs/transformers/v4.21.0/en/model_doc/clip#transformers.CLIPTokenizer).
        tokenizer_3 (`T5TokenizerFast`):
            Tokenizer of class
            [T5Tokenizer](https://huggingface.co/docs/transformers/model_doc/t5#transformers.T5Tokenizer).
    """

    _optional_components = []
    _callback_tensor_inputs = ["latents", "prompt_embeds", "negative_prompt_embeds", "negative_pooled_prompt_embeds"]

    def __init__(
        self,
        transformer: SD3Transformer2DModel,
        scheduler: FlowMatchEulerDiscreteScheduler,
        vae: AutoencoderKL,
        text_encoder: CLIPTextModelWithProjection,
        tokenizer: CLIPTokenizer,
        text_encoder_2: CLIPTextModelWithProjection,
        tokenizer_2: CLIPTokenizer,
        text_encoder_3: T5EncoderModel,
        tokenizer_3: T5TokenizerFast,
    ):
        super().__init__()

        self.register_modules(
            vae=vae,
            text_encoder=text_encoder,
            text_encoder_2=text_encoder_2,
            text_encoder_3=text_encoder_3,
            tokenizer=tokenizer,
            tokenizer_2=tokenizer_2,
            tokenizer_3=tokenizer_3,
            transformer=transformer,
            scheduler=scheduler,
        )
        self.vae_scale_factor = 2**3
        self.image_processor = VaeImageProcessor(vae_scale_factor=self.vae_scale_factor)
        self.tokenizer_max_length = self.tokenizer.model_max_length if hasattr(self, "tokenizer") and self.tokenizer is not None else 77
        self.vae_scaling_factor = 1.5305
        self.vae_shift_factor = 0.0609
        self.default_sample_size = 64

    def _get_t5_prompt_embeds(
        self,
        prompt: Union[str, List[str]] = None,
        num_images_per_prompt: int = 1,
     ):
        prompt = [prompt] if isinstance(prompt, str) else prompt
        batch_size = len(prompt)

        if self.text_encoder_3 is None:
            return torch.zeros(
                (batch_size, self.tokenizer_max_length, 4096),
            )

        text_inputs = self.tokenizer_3(
            prompt,
            padding="max_length",
            max_length=self.tokenizer_max_length,
            truncation=True,
            add_special_tokens=True,
            return_tensors="pt",
        )
        text_input_ids = text_inputs.input_ids
        prompt_embeds = torch.from_numpy(self.text_encoder_3(text_input_ids)[0])
        _, seq_len, _ = prompt_embeds.shape
        prompt_embeds = prompt_embeds.repeat(1, num_images_per_prompt, 1)
        prompt_embeds = prompt_embeds.view(batch_size * num_images_per_prompt, seq_len, -1)

        return prompt_embeds

    def _get_clip_prompt_embeds(
        self,
        prompt: Union[str, List[str]],
        num_images_per_prompt: int = 1,
        clip_skip: Optional[int] = None,
        clip_model_index: int = 0,
    ):
        clip_tokenizers = [self.tokenizer, self.tokenizer_2]
        clip_text_encoders = [self.text_encoder, self.text_encoder_2]

        tokenizer = clip_tokenizers[clip_model_index]
        text_encoder = clip_text_encoders[clip_model_index]

        prompt = [prompt] if isinstance(prompt, str) else prompt
        batch_size = len(prompt)

        text_inputs = tokenizer(prompt, padding="max_length", max_length=self.tokenizer_max_length, truncation=True, return_tensors="pt")

        text_input_ids = text_inputs.input_ids
        prompt_embeds = text_encoder(text_input_ids)
        pooled_prompt_embeds = torch.from_numpy(prompt_embeds[0])
        hidden_states = list(prompt_embeds.values())[1:]

        if clip_skip is None:
            prompt_embeds = torch.from_numpy(hidden_states[-2])
        else:
            prompt_embeds = torch.from_numpy(hidden_states[-(clip_skip + 2)])

        _, seq_len, _ = prompt_embeds.shape
        prompt_embeds = prompt_embeds.repeat(1, num_images_per_prompt, 1)
        prompt_embeds = prompt_embeds.view(batch_size * num_images_per_prompt, seq_len, -1)

        pooled_prompt_embeds = pooled_prompt_embeds.repeat(1, num_images_per_prompt, 1)
        pooled_prompt_embeds = pooled_prompt_embeds.view(batch_size * num_images_per_prompt, -1)

        return prompt_embeds, pooled_prompt_embeds

    def encode_prompt(
        self,
        prompt: Union[str, List[str]],
        prompt_2: Union[str, List[str]],
        prompt_3: Union[str, List[str]],
        num_images_per_prompt: int = 1,
        do_classifier_free_guidance: bool = True,
        negative_prompt: Optional[Union[str, List[str]]] = None,
        negative_prompt_2: Optional[Union[str, List[str]]] = None,
        negative_prompt_3: Optional[Union[str, List[str]]] = None,
        prompt_embeds: Optional[torch.FloatTensor] = None,
        negative_prompt_embeds: Optional[torch.FloatTensor] = None,
        pooled_prompt_embeds: Optional[torch.FloatTensor] = None,
        negative_pooled_prompt_embeds: Optional[torch.FloatTensor] = None,
        clip_skip: Optional[int] = None,
    ):
        prompt = [prompt] if isinstance(prompt, str) else prompt
        if prompt is not None:
            batch_size = len(prompt)
        else:
            batch_size = prompt_embeds.shape[0]

        if prompt_embeds is None:
            prompt_2 = prompt_2 or prompt
            prompt_2 = [prompt_2] if isinstance(prompt_2, str) else prompt_2

            prompt_3 = prompt_3 or prompt
            prompt_3 = [prompt_3] if isinstance(prompt_3, str) else prompt_3

            prompt_embed, pooled_prompt_embed = self._get_clip_prompt_embeds(
                prompt=prompt,
                num_images_per_prompt=num_images_per_prompt,
                clip_skip=clip_skip,
                clip_model_index=0,
            )
            prompt_2_embed, pooled_prompt_2_embed = self._get_clip_prompt_embeds(
                prompt=prompt_2,
                num_images_per_prompt=num_images_per_prompt,
                clip_skip=clip_skip,
                clip_model_index=1,
            )
            clip_prompt_embeds = torch.cat([prompt_embed, prompt_2_embed], dim=-1)

            t5_prompt_embed = self._get_t5_prompt_embeds(
                prompt=prompt_3,
                num_images_per_prompt=num_images_per_prompt,
            )

            clip_prompt_embeds = torch.nn.functional.pad(clip_prompt_embeds, (0, t5_prompt_embed.shape[-1] - clip_prompt_embeds.shape[-1]))

            prompt_embeds = torch.cat([clip_prompt_embeds, t5_prompt_embed], dim=-2)
            pooled_prompt_embeds = torch.cat([pooled_prompt_embed, pooled_prompt_2_embed], dim=-1)

        if do_classifier_free_guidance and negative_prompt_embeds is None:
            negative_prompt = negative_prompt or ""
            negative_prompt_2 = negative_prompt_2 or negative_prompt
            negative_prompt_3 = negative_prompt_3 or negative_prompt

            # normalize str to list
            negative_prompt = batch_size * [negative_prompt] if isinstance(negative_prompt, str) else negative_prompt
            negative_prompt_2 = batch_size * [negative_prompt_2] if isinstance(negative_prompt_2, str) else negative_prompt_2
            negative_prompt_3 = batch_size * [negative_prompt_3] if isinstance(negative_prompt_3, str) else negative_prompt_3

            if prompt is not None and type(prompt) is not type(negative_prompt):
                raise TypeError(f"`negative_prompt` should be the same type to `prompt`, but got {type(negative_prompt)} !=" f" {type(prompt)}.")
            elif batch_size != len(negative_prompt):
                raise ValueError(
                    f"`negative_prompt`: {negative_prompt} has batch size {len(negative_prompt)}, but `prompt`:"
                    f" {prompt} has batch size {batch_size}.Please make sure that passed `negative_prompt` matches"
                    " the batch size of `prompt`."                 )

            negative_prompt_embed, negative_pooled_prompt_embed = self._get_clip_prompt_embeds(
                negative_prompt,
                num_images_per_prompt=num_images_per_prompt,
                clip_skip=None,
                clip_model_index=0,
            )
            negative_prompt_2_embed, negative_pooled_prompt_2_embed = self._get_clip_prompt_embeds(
                negative_prompt_2,
                num_images_per_prompt=num_images_per_prompt,
                clip_skip=None,
                clip_model_index=1,
            )
            negative_clip_prompt_embeds = torch.cat([negative_prompt_embed, negative_prompt_2_embed], dim=-1)

            t5_negative_prompt_embed = self._get_t5_prompt_embeds(prompt=negative_prompt_3, num_images_per_prompt=num_images_per_prompt)

            negative_clip_prompt_embeds = torch.nn.functional.pad(
                negative_clip_prompt_embeds,
                (0, t5_negative_prompt_embed.shape[-1] - negative_clip_prompt_embeds.shape[-1]),
            )

            negative_prompt_embeds = torch.cat([negative_clip_prompt_embeds, t5_negative_prompt_embed], dim=-2)
            negative_pooled_prompt_embeds = torch.cat([negative_pooled_prompt_embed, negative_pooled_prompt_2_embed], dim=-1)

        return prompt_embeds, negative_prompt_embeds, pooled_prompt_embeds, negative_pooled_prompt_embeds

    def check_inputs(
        self,
        prompt,
        prompt_2,
        prompt_3,
        height,
        width,
        negative_prompt=None,
        negative_prompt_2=None,
        negative_prompt_3=None,
        prompt_embeds=None, negative_prompt_embeds=None,
        pooled_prompt_embeds=None,
        negative_pooled_prompt_embeds=None,
        callback_on_step_end_tensor_inputs=None,
    ):
        if height % 8 != 0 or width % 8 != 0:
            raise ValueError(f"`height` and `width` have to be divisible by 8 but are {height} and {width}.")

        if callback_on_step_end_tensor_inputs is not None and not all(k in self._callback_tensor_inputs for k in callback_on_step_end_tensor_inputs):
            raise ValueError(
                f"`callback_on_step_end_tensor_inputs` has to be in {self._callback_tensor_inputs}, but found {[k for k in callback_on_step_end_tensor_inputs if k not in self._callback_tensor_inputs]}"
            )

        if prompt is not None and prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `prompt`: {prompt} and `prompt_embeds`: {prompt_embeds}.Please make sure to" " only forward one of the two."             )
        elif prompt_2 is not None and prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `prompt_2`: {prompt_2} and `prompt_embeds`: {prompt_embeds}.Please make sure to" " only forward one of the two."             )
        elif prompt_3 is not None and prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `prompt_3`: {prompt_2} and `prompt_embeds`: {prompt_embeds}.Please make sure to" " only forward one of the two.")
        elif prompt is None and prompt_embeds is None:
            raise ValueError("Provide either `prompt` or `prompt_embeds`.Cannot leave both `prompt` and `prompt_embeds` undefined.")
        elif prompt is not None and (not isinstance(prompt, str) and not isinstance(prompt, list)):
            raise ValueError(f"`prompt` has to be of type `str` or `list` but is {type(prompt)}")
        elif prompt_2 is not None and (not isinstance(prompt_2, str) and not isinstance(prompt_2, list)):
            raise ValueError(f"`prompt_2` has to be of type `str` or `list` but is {type(prompt_2)}")
        elif prompt_3 is not None and (not isinstance(prompt_3, str) and not isinstance(prompt_3, list)):
            raise ValueError(f"`prompt_3` has to be of type `str` or `list` but is {type(prompt_3)}")

        if negative_prompt is not None and negative_prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `negative_prompt`: {negative_prompt} and `negative_prompt_embeds`:"
                f" {negative_prompt_embeds}.Please make sure to only forward one of the two."             )
        elif negative_prompt_2 is not None and negative_prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `negative_prompt_2`: {negative_prompt_2} and `negative_prompt_embeds`:"
                f" {negative_prompt_embeds}.Please make sure to only forward one of the two."             )
        elif negative_prompt_3 is not None and negative_prompt_embeds is not None:
            raise ValueError(
                f"Cannot forward both `negative_prompt_3`: {negative_prompt_3} and `negative_prompt_embeds`:"
                f" {negative_prompt_embeds}.Please make sure to only forward one of the two.")

        if prompt_embeds is not None and negative_prompt_embeds is not None:
            if prompt_embeds.shape != negative_prompt_embeds.shape:
                raise ValueError(
                    "`prompt_embeds` and `negative_prompt_embeds` must have the same shape when passed directly, but"
                    f" got: `prompt_embeds` {prompt_embeds.shape} != `negative_prompt_embeds`"
                    f" {negative_prompt_embeds.shape}."                 )

        if prompt_embeds is not None and pooled_prompt_embeds is None:
            raise ValueError(
                "If `prompt_embeds` are provided, `pooled_prompt_embeds` also have to be passed. Make sure to generate `pooled_prompt_embeds` from the same text encoder that was used to generate `prompt_embeds`."             )

        if negative_prompt_embeds is not None and negative_pooled_prompt_embeds is None:
            raise ValueError(
                "If `negative_prompt_embeds` are provided, `negative_pooled_prompt_embeds` also have to be passed. Make sure to generate `negative_pooled_prompt_embeds` from the same text encoder that was used to generate `negative_prompt_embeds`."            )

    def prepare_latents(self, batch_size, num_channels_latents, height, width, generator, latents=None):
        if latents is not None:
            return latents

        shape = (batch_size, num_channels_latents, int(height) // self.vae_scale_factor, int(width) // self.vae_scale_factor)

        if isinstance(generator, list) and len(generator) != batch_size:
            raise ValueError(
                f"You have passed a list of generators of length {len(generator)}, but requested an effective batch"
                f" size of {batch_size}.Make sure the batch size matches the length of the generators."            )

        latents = randn_tensor(shape, generator=generator, device=torch.device("cpu"), dtype=torch.float32)

        return latents

    @property
    def guidance_scale(self):
        return self._guidance_scale

    @property
    def clip_skip(self):
        return self._clip_skip

    # ここで、`guidance_scale` は、Imagen 論文の式 (2) のガイダンス重み`w`と
    # 同様に定義されます: https://arxiv.org/pdf/2205.11487.pdf。 `guidance_scale = 1`
    # は、分類器のフリーガイダンスを行わないことに相当します
    @property
    def do_classifier_free_guidance(self):
        return self._guidance_scale > 1

    @property
    def joint_attention_kwargs(self):
        return self._joint_attention_kwargs

    @property
    def num_timesteps(self):
        return self._num_timesteps

    @property
    def interrupt(self):
        return self._interrupt

    @torch.no_grad()
    def __call__(
        self,
        prompt: Union[str, List[str]] = None,
        prompt_2: Optional[Union[str, List[str]]] = None,
        prompt_3: Optional[Union[str, List[str]]] = None,
        height: Optional[int] = None,
        width: Optional[int] = None, num_inference_steps:
        int = 28,
        timesteps: List[int] = None,
        guidance_scale: float = 7.0,
        negative_prompt: Optional[Union[str, List[str]]] = None,
        negative_prompt_2: Optional[Union[str, List[str]]] = None,
        negative_prompt_3: Optional[Union[str, List[str]]] = None,
        num_images_per_prompt: Optional[int] = 1,
        generator: Optional[Union[torch.Generator, List[torch.Generator]]] = None,
        latents: Optional[torch.FloatTensor] = None,
        prompt_embeds: Optional[torch.FloatTensor] = None,
        negative_prompt_embeds: Optional[torch.FloatTensor] = None,
        pooled_prompt_embeds: Optional[torch.FloatTensor] = None,
        negative_pooled_prompt_embeds: Optional[torch.FloatTensor] = None,
        output_type: Optional[str] = "pil",
        return_dict: bool = True,
        clip_skip: Optional[int] = None,
        callback_on_step_end: Optional[Callable[[int, int, Dict], None]] = None,
        callback_on_step_end_tensor_inputs: List[str] = ["latents"],
    ):
        height = height or self.default_sample_size * self.vae_scale_factor
        width = width or self.default_sample_size * self.vae_scale_factor

    # 1. 入力を確認。正しくない場合はエラーを発生
    self.check_inputs(
        prompt,
        prompt_2,
        prompt_3,
        height,
        width,
        negative_prompt=negative_prompt,
        negative_prompt_2=negative_prompt_2,
        negative_prompt_3=negative_prompt_3,
        prompt_embeds=prompt_embeds,
        negative_prompt_embeds=negative_prompt_embeds,
        pooled_prompt_embeds=pooled_prompt_embeds,
        negative_pooled_prompt_embeds=negative_pooled_prompt_embeds,
        callback_on_step_end_tensor_inputs=callback_on_step_end_tensor_inputs,
    )

    self._guidance_scale = guidance_scale
    self._clip_skip = clip_skip
    self._interrupt = False

    # 2. 呼び出しパラメーターを定義
    if prompt is not None and isinstance(prompt, str):
        batch_size = 1
    elif prompt is not None and isinstance(prompt, list):
        batch_size = len(prompt)
    else:
        batch_size = prompt_embeds.shape[0]
    results = self.encode_prompt(
        prompt=prompt,
        prompt_2=prompt_2,
        prompt_3=prompt_3,
        negative_prompt=negative_prompt,
        negative_prompt_2=negative_prompt_2,
        negative_prompt_3=negative_prompt_3,
        do_classifier_free_guidance=self.do_classifier_free_guidance,
        prompt_embeds=prompt_embeds,
        negative_prompt_embeds=negative_prompt_embeds,
        pooled_prompt_embeds=pooled_prompt_embeds,
        negative_pooled_prompt_embeds=negative_pooled_prompt_embeds,
        clip_skip=self.clip_skip,
        num_images_per_prompt=num_images_per_prompt,
    )

    (prompt_embeds, negative_prompt_embeds, pooled_prompt_embeds, negative_pooled_prompt_embeds) = results

    if self.do_classifier_free_guidance:
        prompt_embeds = torch.cat([negative_prompt_embeds, prompt_embeds], dim=0)
        pooled_prompt_embeds = torch.cat([negative_pooled_prompt_embeds, pooled_prompt_embeds], dim=0)

    # 4. タイムステップを準備
    timesteps, num_inference_steps = retrieve_timesteps(self.scheduler, num_inference_steps, timesteps)
    num_warmup_steps = max(len(timesteps) - num_inference_steps * self.scheduler.order, 0)
    self._num_timesteps = len(timesteps)

    # 5. 潜在変数を準備
    num_channels_latents = 16
    latents = self.prepare_latents(batch_size * num_images_per_prompt, num_channels_latents, height, width, generator, latents)

    # 6. ノイズ除去ループ
    with self.progress_bar(total=num_inference_steps) as progress_bar:
        for i, t in enumerate(timesteps):
            if self.interrupt:
                continue

            # 分類器フリーのガイダンスを行う場合は潜在変数を拡張
            latent_model_input = torch.cat([latents] * 2) if self.do_classifier_free_guidance else latents

            # ONNX/Core ML と互換性のある方法でバッチ次元にブロードキャスト
            timestep = t.expand(latent_model_input.shape[0])

            noise_pred = self.transformer([latent_model_input, prompt_embeds, pooled_prompt_embeds, timestep])[0]

            noise_pred = torch.from_numpy(noise_pred)

            # ガイダンスを行う
            if self.do_classifier_free_guidance:
                noise_pred_uncond, noise_pred_text = noise_pred.chunk(2)
                noise_pred = noise_pred_uncond + self.guidance_scale * (noise_pred_text - noise_pred_uncond)

            # 前のノイズサンプルを計算 x_t -> x_t-1
            latents = self.scheduler.step(noise_pred, t, latents, return_dict=False)[0]

            if callback_on_step_end is not None:
                callback_kwargs = {}
                for k in callback_on_step_end_tensor_inputs:
                    callback_kwargs[k] = locals()[k]
                callback_outputs = callback_on_step_end(self, i, t, callback_kwargs)

                latents = callback_outputs.pop("latents", latents)
                prompt_embeds = callback_outputs.pop("prompt_embeds", prompt_embeds)
                negative_prompt_embeds = callback_outputs.pop("negative_prompt_embeds", negative_prompt_embeds)
                negative_pooled_prompt_embeds = callback_outputs.pop("negative_pooled_prompt_embeds", negative_pooled_prompt_embeds)

            # コールバックが提供されている場合はそれを呼び出す
            if i == len(timesteps) - 1 or ((i + 1) > num_warmup_steps and (i + 1) % self.scheduler.order == 0):
                progress_bar.update()

        if output_type == "latent":
            image = latents
        else:
            latents = (latents / self.vae_scaling_factor) + self.vae_shift_factor
            image = torch.from_numpy(self.vae(latents)[0])
            image = self.image_processor.postprocess(image, output_type=output_type)

        if not return_dict:
            return (image,)

        return StableDiffusion3PipelineOutput(images=image)

device = widgets.Dropdown(
    options=core.available_devices + ["AUTO"],
    value="CPU",
    description="Device:",
    disabled=False,
)

device

use_int4_transformer = widgets.Checkbox(value=TRANSFORMER_INT4_PATH.exists(), description="INT4 transformer", disabled=not TRANSFORMER_INT4_PATH.exists())

use_int4_t5 = widgets.Checkbox(value=TEXT_ENCODER_3_INT4_PATH.exists(), description="INT4 t5 text encoder", disabled=not TEXT_ENCODER_3_INT4_PATH.exists())

v_box_widgets = []
if TRANSFORMER_INT4_PATH.exists():
    v_box_widgets.append(use_int4_transformer)

if load_t5.value and TEXT_ENCODER_3_INT4_PATH.exists():
    v_box_widgets.append(use_int4_t5)

if v_box_widgets:
    model_options = widgets.VBox(v_box_widgets)
    display(model_options)

ov_config = {}
if "GPU" in device.value:
    ov_config["INFERENCE_PRECISION_HINT"] = "f32"

transformer = core.compile_model(TRANSFORMER_PATH if not use_int4_transformer.value else TRANSFORMER_INT4_PATH, device.value)
text_encoder_3 = (
    core.compile_model(TEXT_ENCODER_3_PATH if not use_int4_t5.value else TEXT_ENCODER_3_INT4_PATH, device.value, ov_config) if load_t5.value else None
)
text_encoder = core.compile_model(TEXT_ENCODER_PATH, device.value, ov_config)
text_encoder_2 = core.compile_model(TEXT_ENCODER_2_PATH, device.value, ov_config)
vae = core.compile_model(VAE_DECODER_PATH, device.value)

from diffusers.schedulers import FlowMatchEulerDiscreteScheduler, FlashFlowMatchEulerDiscreteScheduler
from transformers import AutoTokenizer

scheduler = (
    FlowMatchEulerDiscreteScheduler.from_pretrained(MODEL_DIR / "scheduler")
    if not use_flash_lora.value
    else FlashFlowMatchEulerDiscreteScheduler.from_pretrained(MODEL_DIR / "scheduler")
)

tokenizer = AutoTokenizer.from_pretrained(MODEL_DIR / "tokenizer")
tokenizer_2 = AutoTokenizer.from_pretrained(MODEL_DIR / "tokenizer_2")
tokenizer_3 = AutoTokenizer.from_pretrained(MODEL_DIR / "tokenizer_3") if load_t5.value else None

ov_pipe = OVStableDiffusion3Pipeline(transformer, scheduler, vae, text_encoder, tokenizer, text_encoder_2, tokenizer_2, text_encoder_3, tokenizer_3)

image = ov_pipe(
    "A raccoon trapped inside a glass jar full of colorful candies, the background is steamy with vivid colors",
    negative_prompt="",
    num_inference_steps=28 if not use_flash_lora.value else 4,
    guidance_scale=5 if not use_flash_lora.value else 0,
    height=512,
    width=512,
    generator=torch.Generator().manual_seed(141),
).images[0]


import gradio as gr
import numpy as np
import random

MAX_SEED = np.iinfo(np.int32).max
MAX_IMAGE_SIZE = 1344

def infer(prompt, negative_prompt, seed, randomize_seed, width, height, guidance_scale, num_inference_steps, progress=gr.Progress(track_tqdm=True)):
    if randomize_seed:
        seed = random.randint(0, MAX_SEED)

    generator = torch.Generator().manual_seed(seed)

    image = ov_pipe(
        prompt=prompt,
        negative_prompt=negative_prompt,
        guidance_scale=guidance_scale,
        num_inference_steps=num_inference_steps,
        width=width,
        height=height,
        generator=generator,
    ).images[0]

    return image, seed

examples = [
    "Astronaut in a jungle, cold color palette, muted colors, detailed, 8k",
    "An astronaut riding a green horse",
    "A delicious ceviche cheesecake slice",
    "A panda reading a book in a lush forest.",
    "A 3d render of a futuristic city with a giant robot in the middle full of neon lights, pink and blue colors",
    'a wizard kitten holding a sign saying "openvino" with a magic wand.',
    "photo of a huge red cat with green eyes sitting on a cloud in the sky, looking at the camera",
    "Pirate ship sailing on a sea with the milky way galaxy in the sky and purple glow lights",
 ]

css = """
#col-container {
    margin: 0 auto;
    max-width: 580px;
}
"""

with gr.Blocks(css=css) as demo:
    with gr.Column(elem_id="col-container"):
        gr.Markdown(

        """
        # Demo [Stable Diffusion 3 Medium](https://huggingface.co/stabilityai/stable-diffusion-3-medium) with OpenVINO
        """
        )

        with gr.Row():
            prompt = gr.Text(
                label="Prompt",
                show_label=False,
                max_lines=1,
                placeholder="Enter your prompt",
                container=False,
            )

            run_button = gr.Button("Run", scale=0)

        result = gr.Image(label="Result", show_label=False)

        with gr.Accordion("Advanced Settings", open=False):
            negative_prompt = gr.Text(
                label="Negative prompt",
                max_lines=1,
                placeholder="Enter a negative prompt",
            )

            seed = gr.Slider(
                label="Seed",
                minimum=0,
                maximum=MAX_SEED,
                step=1,
                value=0,
            )

            randomize_seed = gr.Checkbox(label="Randomize seed", value=True)

            with gr.Row():
                width = gr.Slider(
                    label="Width",
                    minimum=256,
                    maximum=MAX_IMAGE_SIZE,
                    step=64,
                    value=512,
                )

                height = gr.Slider(
                    label="Height",
                    minimum=256,
                    maximum=MAX_IMAGE_SIZE,
                    step=64,
                    value=512,
                )
            with gr.Row():
                guidance_scale = gr.Slider(
                    label="Guidance scale",
                    minimum=0.0,
                    maximum=10.0 if not use_flash_lora.value else 2, step=0.1,
                    value=5.0 if not use_flash_lora.value else 0,
                )

                num_inference_steps = gr.Slider(
                    label="Number of inference steps",
                    minimum=1,
                    maximum=50,
                    step=1,
                    value=28 if not use_flash_lora.value else 4,
                )

        gr.Examples(examples=examples, inputs=[prompt])
    gr.on(
        triggers=[run_button.click, prompt.submit, negative_prompt.submit],
        fn=infer,
        inputs=[prompt, negative_prompt, seed, randomize_seed, width, height, guidance_scale, num_inference_steps],
        outputs=[result, seed],
    )

# リモートで起動する場合は、server_name と server_port を指定
# demo.launch(server_name='your server name', server_port='server port in int')
# プラットフォーム上で起動する際に問題がある場合は、起動メソッドに share=True を渡すことができます:
# demo.launch(share=True)
# インターフェイスの公開共有可能なリンクを作成。詳細はドキュメントをご覧ください: https://gradio.app/docs/
try:
    demo.launch(debug=False)
except Exception:
    demo.launch(debug=False, share=True)
