MobileVLM と OpenVINO によるモバイル言語アシスタント#

%pip install -q "torch>=2.1.0" "timm>=0.9.12" --extra-index-url "https://download.pytorch.org/whl/cpu"
%pip install -q "transformers>=4.33.1,<4.35.0" accelerate "sentencepiece>=0.1.99" "openvino>=2023.2.0" "nncf>=2.7.0" ipywidgets numpy "gradio>=4.19"

from pathlib import Path

import sys
MOBILEVLM_REPO_DIR = Path("./MobileVLM")
if not MOBILEVLM_REPO_DIR.exists():
     !git clone -q "https://github.com/Meituan-AutoML/MobileVLM.git"
sys.path.insert(0, str(MOBILEVLM_REPO_DIR))

import warnings
import itertools
import gc
from typing import Optional, List, Tuple

from mobilevlm.model.mobilevlm import load_pretrained_model
from mobilevlm.conversation import conv_templates, SeparatorStyle
from mobilevlm.utils import (
    disable_torch_init,
    process_images,
    tokenizer_image_token,
    KeywordsStoppingCriteria,
)
from mobilevlm.constants import IMAGE_TOKEN_INDEX, DEFAULT_IMAGE_TOKEN
import PIL
import torch
import transformers
import numpy as np
import gradio as gr
import openvino as ov
import nncf
import ipywidgets as widgets

MODELS_DIR = Path("./models")
MODEL_PATH = "mtgv/MobileVLM-1.7B"

TEMPERATURE = 0.2
TOP_P = None
NUM_BEAMS = 1
MAX_NEW_TOKENS = 512

IMAGE_PATH = MOBILEVLM_REPO_DIR / "assets" / "samples" / "demo.jpg"
PROMPT_STR = "Who is the author of this book?\nAnswer the question using a single word or phrase."

model_name = MODEL_PATH.split("/")[-1]
disable_torch_init()
with warnings.catch_warnings():
    warnings.simplefilter("ignore")
    tokenizer, model, image_processor, _ = load_pretrained_model(MODEL_PATH, device="cpu")
model = model.to(dtype=torch.float32)

def cleanup_torchscript_cache():
    """
    Helper for removing cached model representation
    """
    torch._C._jit_clear_class_registry()
    torch.jit._recursive.concrete_type_store = torch.jit._recursive.ConcreteTypeStore()
    torch.jit._state._clear_class_state()

compression_mode = widgets.Dropdown(
nncf.compress_weightsoptions=["INT4", "INT8"],
nncf.compress_weightsvalue="INT4",
nncf.compress_weightsdescription="Compression mode:",
nncf.compress_weightsdisabled=False,
)

compression_mode

stage1_xml_path = MODELS_DIR / f"stage1_{compression_mode.value}.xml"
stage2_xml_path = MODELS_DIR / f"stage2_{compression_mode.value}.xml"

if compression_mode.value == "INT4":
    wc_parameters = dict(mode=nncf.CompressWeightsMode.INT4_ASYM, group_size=128, ratio=0.8)
else:
    wc_parameters = dict(mode=nncf.CompressWeightsMode.INT8)

class ModelWrapper(torch.nn. Module):
    def __init__(self, model):
        super().__init__()
        self.model = model

    def forward(
        self,
        input_ids: torch.LongTensor = None,
        attention_mask: Optional[torch.Tensor] = None,
        past_key_values: Optional[List[torch.FloatTensor]] = None,
        inputs_embeds: Optional[torch.FloatTensor] = None,
    ):
        outputs = self.model.model(
            input_ids=input_ids,
            attention_mask=attention_mask,
            past_key_values=past_key_values,
            inputs_embeds=inputs_embeds,
        )
        hidden_states = outputs[0]
        logits = self.model.lm_head(hidden_states)

        return (logits,) + outputs[1:]

def set_input_names(model, past_key_values):
    input_names = [
        "input_ids",
        "attention_mask",
        *itertools.chain.from_iterable([f"past_key_values.{idx}.key", f"past_key_values.{idx}.value"] for idx, _ in enumerate(past_key_values)),
    ]
    assert len(input_names) == len(model.inputs)
    for _input, input_name in zip(model.inputs, input_names):         _input.get_tensor().set_names({input_name})

def set_output_names(model, past_key_values):
    output_names = [
        "logits",
        *itertools.chain.from_iterable([f"present.{idx}.key", f"present.{idx}.value"] for idx, _ in enumerate(past_key_values)),
    ]
    assert len(output_names) == len(model.outputs)
    for out, out_name in zip(ov_model.outputs, output_names):
        out.get_tensor().set_names({out_name})

example_input = {
    "inputs_embeds": torch.zeros((1, 205, 2048)),
    "attention_mask": torch.ones((1, 205), dtype=torch.long),
}

wrapped = ModelWrapper(model)
past_key_values = wrapped(**example_input)[1]

if not stage1_xml_path.exists():
    ov_model = ov.convert_model(wrapped, example_input=example_input)
    set_output_names(ov_model, past_key_values)
    ov_model = nncf.compress_weights(ov_model, **wc_parameters)
    ov.save_model(ov_model, stage1_xml_path)
    cleanup_torchscript_cache()
    del ov_model
    gc.collect()

example_input = {
    "input_ids": torch.ones((1, 1), dtype=torch.long),
    "past_key_values": past_key_values,
    "attention_mask": torch.ones((1, past_key_values[-1][-1].shape[-2] + 1), dtype=torch.long),
}

if not stage2_xml_path.exists():
    ov_model = ov.convert_model(
        wrapped,
        example_input=example_input,
    )
    set_input_names(ov_model, past_key_values)
    set_output_names(ov_model, past_key_values)
    ov_model = nncf.compress_weights(ov_model, **wc_parameters)
    ov.save_model(ov_model, stage2_xml_path)
    cleanup_torchscript_cache()
    del ov_model
    gc.collect()

prepare_inputs_labels_for_multimodal = model.prepare_inputs_labels_for_multimodal
prepare_inputs_for_generation = model.prepare_inputs_for_generation
config = model.config
config.save_pretrained(MODELS_DIR)

del wrapped
del model
gc.collect();

class OVMobileLlamaForCausalLM(transformers.GenerationMixin):
    def __init__(self, stage1_path, stage2_path, device):
        self.stage1 = core.compile_model(stage1_path, device)
        self.stage2 = core.read_model(stage2_path)
        self.generation_config = transformers.GenerationConfig.from_model_config(config)
        self.config = transformers.AutoConfig.from_pretrained(MODELS_DIR)
        self.main_input_name = "input_ids"
        self.device = torch.device("cpu")
        self.prepare_inputs_for_generation = prepare_inputs_for_generation
        self.num_pkv = 2
        self.input_names = {key.get_any_name(): idx for idx, key in enumerate(self.stage2.inputs)}
        self.output_names = {key.get_any_name(): idx for idx, key in enumerate(self.stage2.outputs)}
        self.key_value_input_names = [key for key in self.input_names if "key_values" in key]
        self.key_value_output_names = [key for key in self.output_names if "present" in key]
        stage2 = core.compile_model(self.stage2, device)
        self.request = stage2.create_infer_request()
        self._supports_cache_class = False

    def can_generate(self):
        """Returns True to validate the check that the model using `GenerationMixin.generate()` can indeed generate."""
        return True

    def __call__(
        self,
        input_ids: torch.LongTensor,
        images: torch.Tensor,
        attention_mask: Optional[torch.LongTensor] = None,
        prefix_mask: Optional[torch.LongTensor] = None,
        past_key_values: Optional[Tuple[Tuple[torch.FloatTensor]]] = None,
        **kwargs,
    ) -> transformers.modeling_outputs.CausalLMOutputWithPast:
        return self.forward(input_ids, images, attention_mask, prefix_mask, past_key_values)

    def forward(
        self,
        input_ids: torch.LongTensor,
        images: torch.Tensor,
        attention_mask: Optional[torch.LongTensor] = None,
        prefix_mask: Optional[torch.LongTensor] = None,
        past_key_values: Optional[Tuple[Tuple[torch.FloatTensor]]] = None,
        **kwargs,
    ) -> transformers.modeling_outputs.CausalLMOutputWithPast:
        """General inference method"""
        inputs = {}
        if past_key_values is not None:
            # past_key_values をフラット化
            attention_mask = torch.ones(
                (input_ids.shape[0], past_key_values[-1][-1].shape[-2] + 1),
                dtype=input_ids.dtype,
            )
            past_key_values = tuple(past_key_value for pkv_per_layer in past_key_values for past_key_value in pkv_per_layer)
            # past_key_values をデコーダー入力に追加
            inputs = dict(zip(self.key_value_input_names, past_key_values))

        else:
            return self.forward_with_image(input_ids, images, attention_mask)
        inputs["input_ids"] = np.array(input_ids)

        if "attention_mask" in self.input_names:
            inputs["attention_mask"] = np.array(attention_mask)

        # 推論を実行
        self.request.start_async(inputs, share_inputs=True)
        self.request.wait()

        logits = torch.from_numpy(self.request.get_tensor("logits").data)

        # 長さが等しいタプル: レイヤー数 * デコーダーレイヤーごとの past_key_value の数 (2 は自己注意レイヤーに対応)
        past_key_values = tuple(self.request.get_tensor(key).data for key in self.key_value_output_names)
        # 長さが `n_layers` のタプルのタプル。各タプルの長さは 2 (自己注意の k/v) に等しい

        past_key_values = tuple(past_key_values[i : i + self.num_pkv] for i in range(0, len(past_key_values), self.num_pkv))

        return transformers.modeling_outputs.CausalLMOutputWithPast(logits=logits, past_key_values=past_key_values)

    def forward_with_image(self, input_ids, images, attention_mask):
        """First step inference method, that resolves multimodal data"""
        _, attention_mask, _, input_embed, _ = prepare_inputs_labels_for_multimodal(input_ids, attention_mask, images=images, past_key_values=None, labels=None)
        outs = self.stage1({"inputs_embeds": input_embed, "attention_mask": attention_mask})
        logits = outs[0]
        pkv = list(outs.values())[1:]
        pkv = tuple(pkv[i : i + self.num_pkv] for i in range(0, len(pkv), self.num_pkv))
        return transformers.modeling_outputs.CausalLMOutputWithPast(logits=torch.from_numpy(logits), past_key_values=pkv)

core = ov.Core()

device = widgets.Dropdown(
    options=core.available_devices + ["AUTO"],
    value="AUTO",
    description="Device:",
    disabled=False,
)

device

def generate(img, prompt):
    images_tensor = process_images([img], image_processor, transformers.AutoConfig.from_pretrained(MODELS_DIR))
    prompt = DEFAULT_IMAGE_TOKEN + "\n" + prompt
    conv = conv_templates["v1"].copy()
    conv.append_message(conv.roles[0], prompt)
    conv.append_message(conv.roles[1], None)
    prompt = conv.get_prompt()
    stop_str = conv.sep if conv.sep_style != SeparatorStyle.TWO else conv.sep2
    input_ids = tokenizer_image_token(prompt, tokenizer, IMAGE_TOKEN_INDEX, return_tensors="pt").unsqueeze(0)
    stopping_criteria = KeywordsStoppingCriteria([stop_str], tokenizer, input_ids)

    output_ids = ov_model.generate(
        input_ids,
        images=images_tensor,
        do_sample=True if TEMPERATURE > 0 else False, temperature=TEMPERATURE,
        top_p=TOP_P,
        num_beams=NUM_BEAMS,
        max_new_tokens=MAX_NEW_TOKENS,
        use_cache=True,
        stopping_criteria=[stopping_criteria],
    )
    input_token_len = input_ids.shape[1]
    outputs = tokenizer.batch_decode(output_ids[:, input_token_len:], skip_special_tokens=True)[0]
    outputs = outputs.strip()
    if outputs.endswith(stop_str):
        outputs = outputs[: -len(stop_str)]

    return outputs.strip()

demo = gr.Interface(
    generate,
    [gr.Image(label="Image", type="pil"), gr.Textbox(label="Prompt")],
    gr.Textbox(),
    examples=[
        [
            str(IMAGE_PATH),
            PROMPT_STR,
        ]
    ],
    allow_flagging="never",
)

try:
    demo.launch(debug=False)
except Exception:
    demo.launch(debug=False, share=True)
# リモートで起動する場合は、server_name と server_port を指定
# demo.launch(server_name='your server name', server_port='server port in int')
# 詳細はドキュメントをご覧ください: https://gradio.app/docs/
