潜在整合性モデルと OpenVINO による画像生成#

%pip install -q "torch>=2.1" --index-url https://download.pytorch.org/whl/cpu
%pip install -q "openvino>=2023.1.0" transformers "diffusers>=0.23.1" pillow "gradio>=4.19" "nncf>=2.7.0" "datasets>=2.14.6" "peft==0.6.2" --extra-index-url https://download.pytorch.org/whl/cpu

import gc
import warnings
from pathlib import Path
from diffusers import DiffusionPipeline
import numpy as np

warnings.filterwarnings("ignore")

TEXT_ENCODER_OV_PATH = Path("model/text_encoder.xml")
UNET_OV_PATH = Path("model/unet.xml")
VAE_DECODER_OV_PATH = Path("model/vae_decoder.xml")

def load_orginal_pytorch_pipeline_componets(skip_models=False, skip_safety_checker=False):
    pipe = DiffusionPipeline.from_pretrained("SimianLuo/LCM_Dreamshaper_v7")
    scheduler = pipe.scheduler
    tokenizer = pipe.tokenizer
    feature_extractor = pipe.feature_extractor if not skip_safety_checker else None
    safety_checker = pipe.safety_checker if not skip_safety_checker else None
    text_encoder, unet, vae = None, None, None
    if not skip_models:
        text_encoder = pipe.text_encoder
        text_encoder.eval()
        unet = pipe.unet
        unet.eval()
        vae = pipe.vae
        vae.eval()
    del pipe
    gc.collect()
    return (
        scheduler,
        tokenizer,
        feature_extractor,
        safety_checker,
        text_encoder,
        unet,
        vae,
    )

skip_conversion = TEXT_ENCODER_OV_PATH.exists() and UNET_OV_PATH.exists() and VAE_DECODER_OV_PATH.exists()
(
    scheduler,
    tokenizer,
    feature_extractor,
    safety_checker,
    text_encoder,
    unet,
    vae,
) = load_orginal_pytorch_pipeline_componets(skip_conversion)

from typing import Union, Optional, Any, List, Dict
from transformers import CLIPTokenizer, CLIPImageProcessor
from diffusers.pipelines.stable_diffusion.safety_checker import (
    StableDiffusionSafetyChecker,
)
from diffusers.pipelines.stable_diffusion import StableDiffusionPipelineOutput
from diffusers.image_processor import VaeImageProcessor

class OVLatentConsistencyModelPipeline(DiffusionPipeline):
    def __init__(
        self,
        vae_decoder: ov.Model,
        text_encoder: ov.Model,
        tokenizer: CLIPTokenizer,
        unet: ov.Model,
        scheduler: None,
        safety_checker: StableDiffusionSafetyChecker,
        feature_extractor: CLIPImageProcessor,
        requires_safety_checker: bool = True,
    ):
        super().__init__()
        self.vae_decoder = vae_decoder
        self.text_encoder = text_encoder
        self.tokenizer = tokenizer self.register_to_config(unet=unet)
        self.scheduler = scheduler
        self.safety_checker = safety_checker
        self.feature_extractor = feature_extractor
        self.vae_scale_factor = 2**3
        self.image_processor = VaeImageProcessor(vae_scale_factor=self.vae_scale_factor)

    def _encode_prompt(
        self,
        prompt,
        num_images_per_prompt,
        prompt_embeds: None,
    ):
        r"""
        Encodes the prompt into text encoder hidden states.
        Args:
            prompt (`str` or `List[str]`, *optional*):
                prompt to be encoded
            num_images_per_prompt (`int`):
                number of images that should be generated per prompt
            prompt_embeds (`torch.FloatTensor`, *optional*):
                Pre-generated text embeddings. Can be used to easily tweak text inputs, *e.g.* prompt weighting. If not
                provided, text embeddings will be generated from `prompt` input argument.
        """

        if prompt_embeds is None:
            text_inputs = self.tokenizer(
                prompt,
                padding="max_length",
                max_length=self.tokenizer.model_max_length,
                truncation=True,
                return_tensors="pt",
            )
            text_input_ids = text_inputs.input_ids

            prompt_embeds = self.text_encoder(text_input_ids, share_inputs=True, share_outputs=True)
            prompt_embeds = torch.from_numpy(prompt_embeds[0])

        bs_embed, seq_len, _ = prompt_embeds.shape
        # プロンプトごとに各世代のテキスト埋め込みを複製
        prompt_embeds = prompt_embeds.repeat(1, num_images_per_prompt, 1)
        prompt_embeds = prompt_embeds.view(bs_embed * num_images_per_prompt, seq_len, -1)

        # LCM ガイド蒸留により、無条件プロンプト埋め込みを取得する必要はありません
        return prompt_embeds

    def run_safety_checker(self, image, dtype):
        if self.safety_checker is None:
            has_nsfw_concept = None
        else:
            if torch.is_tensor(image):
                feature_extractor_input = self.image_processor.postprocess(image, output_type="pil")
            else:
                feature_extractor_input = self.image_processor.numpy_to_pil(image)
            safety_checker_input = self.feature_extractor(feature_extractor_input, return_tensors="pt")
            image, has_nsfw_concept = self.safety_checker(images=image, clip_input=safety_checker_input.pixel_values.to(dtype))
        return image, has_nsfw_concept

    def prepare_latents(self, batch_size, num_channels_latents, height, width, dtype, latents=None):
        shape = (
            batch_size,
            num_channels_latents,
            height // self.vae_scale_factor,
            width // self.vae_scale_factor,
        )
        if latents is None:
            latents = torch.randn(shape, dtype=dtype)
        # スケジューラーが要求する標準偏差で初期ノイズをスケール
        latents = latents * self.scheduler.init_noise_sigma
        return latents

    def get_w_embedding(self, w, embedding_dim=512, dtype=torch.float32):
        """
        see https://github.com/google-research/vdm/blob/dc27b98a554f65cdc654b800da5aa1846545d41b/model_vdm.py#L298
        Args:
        timesteps: torch.Tensor: generate embedding vectors at these timesteps
        embedding_dim: int: dimension of the embeddings to generate
        dtype: data type of the generated embeddings
        Returns:
        embedding vectors with shape `(len(timesteps), embedding_dim)`
        """
        assert len(w.shape) == 1
        w = w * 1000.0

        half_dim = embedding_dim // 2
        emb = torch.log(torch.tensor(10000.0)) / (half_dim - 1)
        emb = torch.exp(torch.arange(half_dim, dtype=dtype) * -emb)
        emb = w.to(dtype)[:, None] * emb[None, :]
        emb = torch.cat([torch.sin(emb), torch.cos(emb)], dim=1)
        if embedding_dim % 2 == 1: # ゼロパディング
            emb = torch.nn.functional.pad(emb, (0, 1))
            assert emb.shape == (w.shape[0], embedding_dim)
            return emb

    @torch.no_grad()
    def __call__(
        self,
        prompt: Union[str, List[str]] = None,
        height: Optional[int] = 512,
        width: Optional[int] = 512,
        guidance_scale: float = 7.5,
        num_images_per_prompt: Optional[int] = 1,
        latents: Optional[torch.FloatTensor] = None,
        num_inference_steps: int = 4,
        lcm_origin_steps: int = 50,
        prompt_embeds: Optional[torch.FloatTensor] = None,
        output_type: Optional[str] = "pil",
        return_dict: bool = True,
        cross_attention_kwargs: Optional[Dict[str, Any]] = None,
    ):
        # 1. 呼び出しパラメーターを定義
        if prompt is not None and isinstance(prompt, str):
            batch_size = 1
        elif prompt is not None and isinstance(prompt, list):
            batch_size = len(prompt)
        else:
            batch_size = prompt_embeds.shape[0]

        # do_classifier_free_guidance = guidance_scale > 0.0
        # LCM 実装の場合: cfg_noise = noise_cond + cfg_scale * (noise_cond - noise_uncond) , (cfg_scale > 0.0 using CFG)

        # 2. 入力プロンプトをエンコード
        prompt_embeds = self._encode_prompt(
            prompt,
            num_images_per_prompt,
            prompt_embeds=prompt_embeds,
        )

        # 3. タイムステップを準備
        self.scheduler.set_timesteps(num_inference_steps, original_inference_steps=lcm_origin_steps)
        timesteps = self.scheduler.timesteps

        # 4. 潜在変数を準備
        num_channels_latents = 4
        latents = self.prepare_latents(
            batch_size * num_images_per_prompt,
            num_channels_latents,
            height,
            width,
            prompt_embeds.dtype,
            latents,
        )

        bs = batch_size * num_images_per_prompt

        # 5. ガイダンススケールの埋め込みを取得
        w = torch.tensor(guidance_scale).repeat(bs)
        w_embedding = self.get_w_embedding(w, embedding_dim=256)

        # 6. LCM マルチステップ・サンプリング・ループ:
        with self.progress_bar(total=num_inference_steps) as progress_bar:
            for i, t in enumerate(timesteps):
                ts = torch.full((bs,), t, dtype=torch.long)

                # モデル予測 (v-prediction, eps, x)
                model_pred = self.unet(
                    [latents, ts, prompt_embeds, w_embedding],
                    share_inputs=True,
                    share_outputs=True,
                )[0]

                # 前のノイズサンプルを計算 x_t -> x_t-1
                latents, denoised = self.scheduler.step(torch.from_numpy(model_pred), t, latents, return_dict=False)
                progress_bar.update()

        if not output_type == "latent":
            image = torch.from_numpy(self.vae_decoder(denoised / 0.18215, share_inputs=True, share_outputs=True)[0])
            image, has_nsfw_concept = self.run_safety_checker(image, prompt_embeds.dtype)
        else:
                image = denoised
                has_nsfw_concept = None

        if has_nsfw_concept is None:
            do_denormalize = [True] * image.shape[0]
        else:
            do_denormalize = [not has_nsfw for has_nsfw in has_nsfw_concept]

        image = self.image_processor.postprocess(image, output_type=output_type, do_denormalize=do_denormalize)

        if not return_dict:
            return (image, has_nsfw_concept)

        return StableDiffusionPipelineOutput(images=image, nsfw_content_detected=has_nsfw_concept)

prompt = "a beautiful pink unicorn, 8k"
num_inference_steps = 4
torch.manual_seed(1234567)

images = ov_pipe(
    prompt=prompt,
    num_inference_steps=num_inference_steps,
    guidance_scale=8.0,
    lcm_origin_steps=50,
    output_type="pil",
    height=512,
    width=512,
).images

images[0]

skip_for_device = "GPU" in device.value
to_quantize = widgets.Checkbox(value=not skip_for_device, description="Quantization", disabled=skip_for_device)
to_quantize

int8_pipe = None

# `skip_kernel_extension` モジュールを取得
import requests

r = requests.get(

url="https://raw.githubusercontent.com/openvinotoolkit/openvino_notebooks/latest/utils/skip_kernel_extension.py",
)
open("skip_kernel_extension.py", "w").write(r.text)
%load_ext skip_kernel_extension

import random
import gradio as gr
from functools import partial

MAX_SEED = np.iinfo(np.int32).max

examples = [
    "portrait photo of a girl, photograph, highly detailed face, depth of field, moody light, golden hour,"
    "style by Dan Winters, Russell James, Steve McCurry, centered, extremely detailed, Nikon D850, award winning photography",
    "Self-portrait oil painting, a beautiful cyborg with golden hair, 8k",
    "Astronaut in a jungle, cold color palette, muted colors, detailed, 8k",
    "A photo of beautiful mountain with realistic sunset and blue lake, highly detailed, masterpiece",
 ]

def randomize_seed_fn(seed: int, randomize_seed: bool) -> int:
    if randomize_seed:
        seed = random.randint(0, MAX_SEED)
    return seed

MAX_IMAGE_SIZE = 768

def generate(
    pipeline: OVLatentConsistencyModelPipeline,
    prompt: str,
    seed: int = 0,
    width: int = 512,
    height: int = 512,
    guidance_scale: float = 8.0,
    num_inference_steps: int = 4,
    randomize_seed: bool = False,
    num_images: int = 1,
    progress=gr.Progress(track_tqdm=True),
):
    seed = randomize_seed_fn(seed, randomize_seed)
    torch.manual_seed(seed)
    result = pipeline(
        prompt=prompt,
        width=width,
        height=height,
        guidance_scale=guidance_scale,
        num_inference_steps=num_inference_steps,
        num_images_per_prompt=num_images,
        lcm_origin_steps=50,
        output_type="pil",
).images[0]
return result, seed

generate_original = partial(generate, ov_pipe)
generate_optimized = partial(generate, int8_pipe)
quantized_model_present = int8_pipe is not None

with gr.Blocks() as demo:
    with gr.Group():
        with gr.Row():
            prompt = gr.Text(
                label="Prompt",
                show_label=False,
                max_lines=1,
                placeholder="Enter your prompt",
                container=False,
            )
        with gr.Row():
            with gr.Column():
                result = gr.Image(
                    label="Result (Original)" if quantized_model_present else "Image",
                    type="pil",
                )
                run_button = gr.Button("Run")
            with gr.Column(visible=quantized_model_present):
                result_optimized = gr.Image(
                    label="Result (Optimized)",
                    type="pil",
                    visible=quantized_model_present,
                )
                run_quantized_button = gr.Button(value="Run quantized", visible=quantized_model_present)

    with gr.Accordion("Advanced options", open=False):
        seed = gr.Slider(label="Seed", minimum=0, maximum=MAX_SEED, step=1, value=0, randomize=True)
        randomize_seed = gr.Checkbox(label="Randomize seed across runs", value=True)
        with gr.Row():
            width = gr.Slider(
                label="Width",
                minimum=256,
                maximum=MAX_IMAGE_SIZE,
                step=32,
                value=512,
            )
            height = gr.Slider(
                label="Height",
                minimum=256,
                maximum=MAX_IMAGE_SIZE,
                step=32,
                value=512,
            ) with gr.Row():
                guidance_scale = gr.Slider(
                    label="Guidance scale for base",
                    minimum=2,
                    maximum=14,
                    step=0.1,
                    value=8.0,
                )
                num_inference_steps = gr.Slider(
                    label="Number of inference steps for base",
                    minimum=1,
                    maximum=8,
                    step=1,
                    value=4,
                )

    gr.Examples(
        examples=examples,
        inputs=prompt,
        outputs=result,
        cache_examples=False,
    )

    gr.on(
        triggers=[
            prompt.submit,
            run_button.click,
        ],
        fn=generate_original,
        inputs=[
            prompt,
            seed,
            width,
            height,
            guidance_scale,
            num_inference_steps,
            randomize_seed,
        ],
        outputs=[result, seed],
    )

    if quantized_model_present:
        gr.on(
            triggers=[
                prompt.submit,
                run_quantized_button.click,
            ],
            fn=generate_optimized,
            inputs=[
                prompt,
                seed,
                width,
                height,
                guidance_scale,
                num_inference_steps,
                randomize_seed,
            ],
            outputs=[result_optimized, seed],
        )

try:
    demo.queue().launch(debug=False)
except Exception:
    demo.queue().launch(share=True, debug=False)
# リモートで起動する場合は、server_name と server_port を指定
# demo.launch(server_name='your server name', server_port='server port in int')
# 詳細はドキュメントをご覧ください: https://gradio.app/docs/
