SDXL-turbo と OpenVINO を使用したシングルステップの画像生成#

import ipywidgets as widgets

core = ov.Core()
device = widgets.Dropdown(
    options=core.available_devices + ["AUTO"],
    value="AUTO",
    description="Device:",
    disabled=False,
)

device

from optimum.intel.openvino import OVStableDiffusionXLPipeline

text2image_pipe = OVStableDiffusionXLPipeline.from_pretrained(model_dir, device=device.value)

import numpy as np

prompt = "cute cat"
image = text2image_pipe(
    prompt,
    num_inference_steps=1,
    height=512,
    width=512,
    guidance_scale=0.0,
    generator=np.random.RandomState(987),
).images[0]
image.save("cat.png")

del text2image_pipe gc.collect();

UNET_INT8_OV_PATH = model_dir / "optimized_unet" / "openvino_model.xml"

def disable_progress_bar(pipeline, disable=True):
    if not hasattr(pipeline, "_progress_bar_config"):
        pipeline._progress_bar_config = {"disable": disable}
    else:
        pipeline._progress_bar_config["disable"] = disable

%%skip not $to_quantize.value

import datasets
import numpy as np
from tqdm.notebook import tqdm
from transformers import set_seed
from typing import Any, Dict, List

set_seed(1)

class CompiledModelDecorator(ov.CompiledModel):
    def __init__(self, compiled_model: ov.CompiledModel, data_cache: List[Any] = None):
        super().__init__(compiled_model)
        self.data_cache = data_cache if data_cache else []

    def __call__(self, *args, **kwargs):
        self.data_cache.append(*args)
        return super().__call__(*args, **kwargs)

def collect_calibration_data(pipe, subset_size: int) -> List[Dict]:
    original_unet = pipe.unet.request
    pipe.unet.request = CompiledModelDecorator(original_unet)

    dataset = datasets.load_dataset("google-research-datasets/conceptual_captions", split="train", trust_remote_code=True).shuffle(seed=42)
    disable_progress_bar(pipe)

    # Run inference for data collection
    pbar = tqdm(total=subset_size)
    diff = 0
    for batch in dataset:
        prompt = batch["caption"]
        if len(prompt) > pipe.tokenizer.model_max_length:
            continue
            _ = pipe(
                    prompt,
                    num_inference_steps=1,
                    height=512, width=512,
                    guidance_scale=0.0,
                    generator=np.random.RandomState(987)
        )
        collected_subset_size = len(pipe.unet.request.data_cache)
        if collected_subset_size >= subset_size:
            pbar.update(subset_size - pbar.n)
            break
        pbar.update(collected_subset_size - diff)
        diff = collected_subset_size

    calibration_dataset = pipe.unet.request.data_cache
    disable_progress_bar(pipe, disable=False)
    pipe.unet.request = original_unet
    return calibration_dataset

%%skip not $to_quantize.value

if not UNET_INT8_OV_PATH.exists():
    text2image_pipe = OVStableDiffusionXLPipeline.from_pretrained(model_dir, device=device.value)
    unet_calibration_data = collect_calibration_data(text2image_pipe, subset_size=200)

%%skip not $to_quantize.value

import nncf
from nncf.scopes import IgnoredScope

UNET_OV_PATH = model_dir / "unet" / "openvino_model.xml"
if not UNET_INT8_OV_PATH.exists():
    unet = core.read_model(UNET_OV_PATH)
    quantized_unet = nncf.quantize(
        model=unet,
        model_type=nncf.ModelType.TRANSFORMER,
        calibration_dataset=nncf.Dataset(unet_calibration_data),
        ignored_scope=IgnoredScope(
            names=[
                "__module.model.conv_in/aten::_convolution/Convolution",
                "__module.model.up_blocks.2.resnets.2.conv_shortcut/aten::_convolution/Convolution",
                "__module.model.conv_out/aten::_convolution/Convolution"
            ],
        ),
    )
    ov.save_model(quantized_unet, UNET_INT8_OV_PATH)

%%skip not $to_quantize.value

from IPython.display import display

int8_text2image_pipe = OVStableDiffusionXLPipeline.from_pretrained(model_dir, device=device.value, compile=False)
int8_text2image_pipe.unet.model = core.read_model(UNET_INT8_OV_PATH)
int8_text2image_pipe.unet.request = None

prompt = "cute cat"
image = int8_text2image_pipe(prompt, num_inference_steps=1, height=512, width=512, guidance_scale=0.0,
generator=np.random.RandomState(987)).images[0]
display(image)

%%skip not $to_quantize.value

int8_image2image_pipe = OVStableDiffusionXLImg2ImgPipeline.from_pretrained(model_dir, device=device.value, compile=False)
int8_image2image_pipe.unet.model = core.read_model(UNET_INT8_OV_PATH)
int8_image2image_pipe.unet.request = None

photo_prompt = "a cute cat with bow tie"
photo_image = int8_image2image_pipe(photo_prompt, image=image, num_inference_steps=2,
generator=np.random.RandomState(511), guidance_scale=0.0, strength=0.5).images[0]
display(photo_image)

%%skip not $to_quantize.value

import time

validation_size = 7
calibration_dataset = datasets.load_dataset("google-research-datasets/conceptual_captions", split="train", trust_remote_code=True)
validation_data = []
for batch in calibration_dataset:
    prompt = batch["caption"]
    validation_data.append(prompt)

def calculate_inference_time(pipe, dataset):
    inference_time = []
    disable_progress_bar(pipe)

    for idx, prompt in enumerate(dataset):
        start = time.perf_counter()
        image = pipe(
            prompt,
            num_inference_steps=1,
            guidance_scale=0.0,
            generator=np.random.RandomState(23)
        ).images[0]
        end = time.perf_counter()
        delta = end - start
        inference_time.append(delta)
        if idx >= validation_size:
            break
    disable_progress_bar(pipe, disable=False)
    return np.median(inference_time)

%%skip not $to_quantize.value

int8_latency = calculate_inference_time(int8_text2image_pipe, validation_data)
text2image_pipe = OVStableDiffusionXLPipeline.from_pretrained(model_dir, device=device.value)
fp_latency = calculate_inference_time(text2image_pipe, validation_data)
print(f"FP16 pipeline latency: {fp_latency:.3f}")
print(f"INT8 pipeline latency: {int8_latency:.3f}")
print(f"Text-to-Image generation speed up: {fp_latency / int8_latency:.3f}")
