ControlNet QR Code Monster と OpenVINO™ を使用してクリエイティブな QR コードを生成#

%pip install -q accelerate diffusers transformers "torch>=2.1" "gradio>=4.19" qrcode opencv-python "peft==0.6.2" --extra-index-url https://download.pytorch.org/whl/cpu
%pip install -q "openvino>=2023.1.0" "nncf>=2.7.0"

import gc
from functools import partial
from pathlib import Path
from PIL import Image
import openvino as ov
import torch

def cleanup_torchscript_cache():
    """
    Helper for removing cached model representation
    """
    torch._C._jit_clear_class_registry()
    torch.jit._recursive.concrete_type_store = torch.jit._recursive.ConcreteTypeStore()
    torch.jit._state._clear_class_state()

import ipywidgets as widgets

core = ov.Core()

device = widgets.Dropdown(
    options=core.available_devices + ["AUTO"],
    value="CPU",
    description="Device:",
    disabled=False,
)

device

from diffusers import DiffusionPipeline
from transformers import CLIPTokenizer
from typing import Union, List, Optional, Tuple
import cv2
import numpy as np

def scale_fit_to_window(dst_width: int, dst_height: int, image_width: int, image_height: int):
    """
    Preprocessing helper function for calculating image size for resize with peserving original aspect ratio
    and fitting image to specific window size

    Parameters:
        dst_width (int): destination window width
        dst_height (int): destination window height
        image_width (int): source image width
        image_height (int): source image height
    Returns:
        result_width (int): calculated width for resize
        result_height (int): calculated height for resize
    """
    im_scale = min(dst_height / image_height, dst_width / image_width)
    return int(im_scale * image_width), int(im_scale * image_height)

def preprocess(image: Image.Image):
    """
    Image preprocessing function.Takes image in PIL.Image format, resizes it to keep aspect ration and fits to model input window 768x768,
    then converts it to np.ndarray and adds padding with zeros on right or bottom side of image (depends from aspect ratio), after that
    converts data to float32 data type and change range of values from [0, 255] to [-1, 1], finally, converts data layout from planar NHWC to NCHW.
    The function returns preprocessed input tensor and padding size, which can be used in postprocessing.
    Parameters:
        image (Image.Image): input image
    Returns:
        image (np.ndarray): preprocessed image tensor
        pad (Tuple[int]): pading size for each dimension for restoring image size in postprocessing
    """
    src_width, src_height = image.size
    dst_width, dst_height = scale_fit_to_window(768, 768, src_width, src_height)
    image = image.convert("RGB")
    image = np.array(image.resize((dst_width, dst_height), resample=Image.Resampling.LANCZOS))[None, :]
    pad_width = 768 - dst_width
    pad_height = 768 - dst_height
    pad = ((0, 0), (0, pad_height), (0, pad_width), (0, 0))
    image = np.pad(image, pad, mode="constant")
    image = image.astype(np.float32) / 255.0
    image = image.transpose(0, 3, 1, 2)
    return image, pad

def randn_tensor( shape: Union[Tuple, List], dtype: Optional[np.dtype] = np.float32, ):
    """
    Helper function for generation random values tensor with given shape and data type

    Parameters:
        shape (Union[Tuple, List]): shape for filling random values
        dtype (np.dtype, *optiona*, np.float32): data type for result
    Returns:
        latents (np.ndarray): tensor with random values with given data type and shape (usually represents noise in latent space)
    """
    latents = np.random.randn(*shape).astype(dtype)

    return latents

class OVContrlNetStableDiffusionPipeline(DiffusionPipeline):
    """
    OpenVINO inference pipeline for Stable Diffusion with ControlNet guidence
    """

    def __init__(
        self,
        tokenizer: CLIPTokenizer,
        scheduler,
        core: ov.Core,
        controlnet: ov.Model,
        text_encoder: ov.Model,
        unet: ov.Model,
        vae_decoder: ov.Model,
        device: str = "AUTO",
    ):
        super().__init__()
        self.tokenizer = tokenizer
        self.vae_scale_factor = 8
        self.scheduler = scheduler
        self.load_models(core, device, controlnet, text_encoder, unet, vae_decoder)
        self.set_progress_bar_config(disable=True)

    def load_models(
        self,
        core: ov.Core, device: str,
        controlnet: ov.Model,
        text_encoder: ov.Model,
        unet: ov.Model,
        vae_decoder: ov.Model,
    ):
        """
        Function for loading models on device using OpenVINO

        Parameters:
            core (Core): OpenVINO runtime Core class instance
            device (str): inference device
            controlnet (Model): OpenVINO Model object represents ControlNet
            text_encoder (Model): OpenVINO Model object represents text encoder
            unet (Model): OpenVINO Model object represents UNet
            vae_decoder (Model): OpenVINO Model object represents vae decoder
        Returns
            None
        """
        self.text_encoder = core.compile_model(text_encoder, device)
        self.text_encoder_out = self.text_encoder.output(0)
        self.register_to_config(controlnet=core.compile_model(controlnet, device))
        self.register_to_config(unet=core.compile_model(unet, device))
        self.unet_out = self.unet.output(0)
        self.vae_decoder = core.compile_model(vae_decoder, device)
        self.vae_decoder_out = self.vae_decoder.output(0)

    def __call__(
        self,
        prompt: Union[str, List[str]],
        image: Image.Image,
        num_inference_steps: int = 10,
        negative_prompt: Union[str, List[str]] = None,
        guidance_scale: float = 7.5,
        controlnet_conditioning_scale: float = 1.0,
        eta: float = 0.0,
        latents: Optional[np.array] = None,
        output_type: Optional[str] = "pil",
    ):
        """
        Function invoked when calling the pipeline for generation.

        Parameters:
            prompt (`str` or `List[str]`):
                The prompt or prompts to guide the image generation.
            image (`Image.Image`):
                `Image`, or tensor representing an image batch which will be repainted according to `prompt`.
            num_inference_steps (`int`, *optional*, defaults to 100):
                The number of denoising steps.More denoising steps usually lead to a higher quality image at the
                expense of slower inference.
            negative_prompt (`str` or `List[str]`):
                negative prompt or prompts for generation
            guidance_scale (`float`, *optional*, defaults to 7.5):
                Guidance scale as defined in [Classifier-Free Diffusion Guidance](https://arxiv.org/abs/2207.12598).
                `guidance_scale` is defined as `w` of equation 2. of [Imagen
                Paper](https://arxiv.org/pdf/2205.11487.pdf).Guidance scale is enabled by setting `guidance_scale >
                1`. Higher guidance scale encourages to generate images that are closely linked to the text `prompt`,
                usually at the expense of lower image quality.This pipeline requires a value of at least `1`.
            latents (`np.ndarray`, *optional*):
                Pre-generated noisy latents, sampled from a Gaussian distribution, to be used as inputs for image
                generation. Can be used to tweak the same generation with different prompts. If not provided, a latents
                tensor will ge generated by sampling using the supplied random `generator`.
            output_type (`str`, *optional*, defaults to `"pil"`):
                 The output format of the generate image.Choose between
                [PIL](https://pillow.readthedocs.io/en/stable/): `Image.Image` or `np.array`.
            Returns:
            image ([List[Union[np.ndarray, Image.Image]]): generaited images
        """

        # 1. 呼び出しパラメーターを定義
        batch_size = 1 if isinstance(prompt, str) else len(prompt)
        # ここで `guidance_scale` は Imagen 論文の式 (2)
        # のガイダンス重み`w`と同様に定義されます: https://arxiv.org/pdf/2205.11487.pdf`guidance_scale = 1`
        # は、分類器フリーのガイダンスを行わないことに相当
        do_classifier_free_guidance = guidance_scale > 1.0
        # 2. 入力プロンプトをエンコード
        text_embeddings = self._encode_prompt(prompt, negative_prompt=negative_prompt)

        # 3. 画像の前処理
        orig_width, orig_height = image.size
        image, pad = preprocess(image)
        height, width = image.shape[-2:]
        if do_classifier_free_guidance:
            image = np.concatenate(([image] * 2))

        # 4. タイムステップを設定
        self.scheduler.set_timesteps(num_inference_steps)
        timesteps = self.scheduler.timesteps

        # 6. 潜在変数を準備
        num_channels_latents = 4
        latents = self.prepare_latents(
            batch_size,
            num_channels_latents,
            height,
            width,
            text_embeddings.dtype,
            latents,
        )

        # 7. ノイズ除去ループ
        num_warmup_steps = len(timesteps) - num_inference_steps * self.scheduler.order
        with self.progress_bar(total=num_inference_steps) as progress_bar:
            for i, t in enumerate(timesteps):
                # 分類器フリーのガイダンスを実行する場合は潜在変数を拡張
                # pix2pix ではテキストと入力画像の両方にガイダンスが適用されるため、
                # 潜在変数は 3 倍に拡張されます
                latent_model_input = np.concatenate([latents] * 2) if do_classifier_free_guidance else latents
                latent_model_input = self.scheduler.scale_model_input(latent_model_input, t)

                result = self.controlnet([latent_model_input, t, text_embeddings, image])
                down_and_mid_blok_samples = [sample * controlnet_conditioning_scale for _, sample in result.items()]

                # ノイズ残留を予測
                noise_pred = self.unet([latent_model_input, t, text_embeddings, *down_and_mid_blok_samples])[self.unet_out]

                # ガイダンスを実行
                if do_classifier_free_guidance:
                    noise_pred_uncond, noise_pred_text = noise_pred[0], noise_pred[1]
                    noise_pred = noise_pred_uncond + guidance_scale * (noise_pred_text - noise_pred_uncond)

                # 前のノイズサンプル x_t -> x_t-1 を計算
                latents = self.scheduler.step(torch.from_numpy(noise_pred), t, torch.from_numpy(latents)).prev_sample.numpy()

                # 進捗状況の更新
                if i == len(timesteps) - 1 or ((i + 1) > num_warmup_steps and (i + 1) % self.scheduler.order == 0):
                    progress_bar.update()

        # 8. 後処理
        image = self.decode_latents(latents, pad)

        # 9. PIL に変換
        if output_type == "pil":
            image = self.numpy_to_pil(image)
            image = [img.resize((orig_width, orig_height), Image.Resampling.LANCZOS) for img in image]
        else:
            image = [cv2.resize(img, (orig_width, orig_width)) for img in image]

        return image

    def _encode_prompt(
        self,
        prompt: Union[str, List[str]],
        num_images_per_prompt: int = 1,
        do_classifier_free_guidance: bool = True,
        negative_prompt: Union[str, List[str]] = None,
    ):
        """
        Encodes the prompt into text encoder hidden states.

        Parameters:
            prompt (str or list(str)): prompt to be encoded
            num_images_per_prompt (int): number of images that should be generated per prompt
            do_classifier_free_guidance (bool): whether to use classifier free guidance or not
            negative_prompt (str or list(str)): negative prompt to be encoded
        Returns:
            text_embeddings (np.ndarray): text encoder hidden states
        """
        batch_size = len(prompt) if isinstance(prompt, list) else 1

        # 入力プロンプトをトークン化
        text_inputs = self.tokenizer(
            prompt,
            padding="max_length",
            max_length=self.tokenizer.model_max_length,
            truncation=True,
            return_tensors="np",
        )
        text_input_ids = text_inputs.input_ids

        text_embeddings = self.text_encoder(text_input_ids)[self.text_encoder_out]

        # プロンプトごとに各世代のテキスト埋め込みを複製
        if num_images_per_prompt != 1:
            bs_embed, seq_len, _ = text_embeddings.shape
            text_embeddings = np.tile(text_embeddings, (1, num_images_per_prompt, 1))
            text_embeddings = np.reshape(text_embeddings, (bs_embed * num_images_per_prompt, seq_len, -1))

        # 分類器の無条件埋め込みを取得する無料ガイダンス
        if do_classifier_free_guidance:
            uncond_tokens: List[str]
            max_length = text_input_ids.shape[-1]
            if negative_prompt is None:
                uncond_tokens = [""] * batch_size
            elif isinstance(negative_prompt, str):
                uncond_tokens = [negative_prompt]
            else:
                uncond_tokens = negative_prompt
            uncond_input = self.tokenizer(
                uncond_tokens,
                padding="max_length",
                max_length=max_length,
                truncation=True,
                return_tensors="np",
            )

            uncond_embeddings = self.text_encoder(uncond_input.input_ids)[self.text_encoder_out]

            # mps フレンドリーな方法を使用して、プロンプトごとに各世代の無条件埋め込みを複製
            seq_len = uncond_embeddings.shape[1]
            uncond_embeddings = np.tile(uncond_embeddings, (1, num_images_per_prompt, 1))
            uncond_embeddings = np.reshape(uncond_embeddings, (batch_size * num_images_per_prompt, seq_len, -1))

            # 分類器フリーのガイダンスでは、2 回のフォワードパスを実行する必要がある
            # ここでは、無条件埋め込みとテキスト埋め込みを 1 つのバッチに連結して、
            # 2 回のフォワードパスの実行を回避
            text_embeddings = np.concatenate([uncond_embeddings, text_embeddings])

        return text_embeddings

    def prepare_latents(
        self,
        batch_size: int,
        num_channels_latents: int,
        height: int,
        width: int,
        dtype: np.dtype = np.float32,
        latents: np.ndarray = None,
    ):
        """
        Preparing noise to image generation.If initial latents are not provided, they will be generated randomly,
        then prepared latents scaled by the standard deviation required by the scheduler

        Parameters:
            batch_size (int): input batch size
            num_channels_latents (int): number of channels for noise generation
            height (int): image height
            width (int): image width
            dtype (np.dtype, *optional*, np.float32): dtype for latents generation
            latents (np.ndarray, *optional*, None): initial latent noise tensor, if not provided will be generated
        Returns:
            latents (np.ndarray): scaled initial noise for diffusion
        """
        shape = (
            batch_size,
            num_channels_latents,
            height // self.vae_scale_factor,
            width // self.vae_scale_factor,
        )
        if latents is None:
            latents = randn_tensor(shape, dtype=dtype)
        else:
            latents = latents

        # スケジューラーが要求する標準偏差で初期ノイズをスケール
        latents = latents * np.array(self.scheduler.init_noise_sigma)
        return latents

    def decode_latents(self, latents: np.array, pad: Tuple[int]):
        """
        Decode predicted image from latent space using VAE Decoder and unpad image result

        Parameters:
            latents (np.ndarray): image encoded in diffusion latent space
            pad (Tuple[int]): each side padding sizes obtained on preprocessing step
        Returns:
            image: decoded by VAE decoder image
        """
        latents = 1 / 0.18215 * latents
        image = self.vae_decoder(latents)[self.vae_decoder_out]
        (_, end_h), (_, end_w) = pad[1:3]
        h, w = image.shape[2:]
        unpad_h = h - end_h
        unpad_w = w - end_w
        image = image[:, :, :unpad_h, :unpad_w]
        image = np.clip(image / 2 + 0.5, 0, 1)
        image = np.transpose(image, (0, 2, 3, 1))
        return image

import qrcode

def create_code(content: str):
    """Creates QR codes with provided content."""
    qr = qrcode.QRCode(
        version=1,
        error_correction=qrcode.constants.ERROR_CORRECT_H,
        box_size=16,
        border=0,
    )
    qr.add_data(content)
    qr.make(fit=True)
    img = qr.make_image(fill_color="black", back_color="white")

    # QR に適合する 256 の倍数の最小画像サイズを検出
    offset_min = 8 * 16
    w, h = img.size
    w = (w + 255 + offset_min) // 256 * 256
    h = (h + 255 + offset_min) // 256 * 256
    if w > 1024:
        raise RuntimeError("QR code is too large, please use a shorter content")
    bg = Image.new("L", (w, h), 128)

    # 16 ピクセルのグリッドに合わせる
    coords = ((w - img.size[0]) // 2 // 16 * 16, (h - img.size[1]) // 2 // 16 * 16)
    bg.paste(img, coords)
    return bg

from transformers import CLIPTokenizer
from diffusers import EulerAncestralDiscreteScheduler

tokenizer = CLIPTokenizer.from_pretrained("openai/clip-vit-large-patch14")
scheduler = EulerAncestralDiscreteScheduler.from_config(pipe.scheduler.config)

ov_pipe = OVContrlNetStableDiffusionPipeline(
    tokenizer,
    scheduler,
    core,
    controlnet_ir_path,
    text_encoder_ir_path,
    unet_ir_path,
    vae_ir_path,
    device=device.value,
)

np.random.seed(42)

qrcode_image = create_code("Hi OpenVINO")
image = ov_pipe(
    "cozy town on snowy mountain slope 8k",
    qrcode_image,
    negative_prompt="blurry unreal occluded",
    num_inference_steps=25,
    guidance_scale=7.7,
    controlnet_conditioning_scale=1.4,
)[0]


skip_for_device = "GPU" in device.value
to_quantize = widgets.Checkbox(value=not skip_for_device, description="Quantization", disabled=skip_for_device)
to_quantize

# `skip_kernel_extension` モジュールを取得
import requests

r = requests.get(

url="https://raw.githubusercontent.com/openvinotoolkit/openvino_notebooks/latest/utils/skip_kernel_extension.py",
)
open("skip_kernel_extension.py", "w").write(r.text)

int8_pipe = None

%load_ext skip_kernel_extension

quantized_model_present = int8_pipe is not None

use_quantized_model = widgets.Checkbox(
    value=True if quantized_model_present else False,
    description="Use quantized model",
    disabled=not quantized_model_present,
)

use_quantized_model

import gradio as gr

pipeline = int8_pipe if use_quantized_model.value else ov_pipe

def _generate(
    qr_code_content: str,
    prompt: str,
    negative_prompt: str,
    seed: Optional[int] = 42,
    guidance_scale: float = 10.0,
    controlnet_conditioning_scale: float = 2.0,
    num_inference_steps: int = 5,
    progress=gr.Progress(track_tqdm=True),
):
    if seed is not None:
        np.random.seed(int(seed))
    qrcode_image = create_code(qr_code_content)
    return pipeline(
        prompt,
        qrcode_image,
        negative_prompt=negative_prompt,
        num_inference_steps=int(num_inference_steps),
        guidance_scale=guidance_scale,
        controlnet_conditioning_scale=controlnet_conditioning_scale,
    )[0]

demo = gr.Interface(
    _generate,
    inputs=[
        gr.Textbox(label="QR Code content"),
        gr.Textbox(label="Text Prompt"),
        gr.Textbox(label="Negative Text Prompt"),
        gr.Number(
            minimum=-1,
            maximum=9999999999,
            step=1,
            value=42,
            label="Seed",
            info="Seed for the random number generator",
        ),
        gr.Slider(
            minimum=0.0,
            maximum=25.0,
            step=0.25,
            value=7,
            label="Guidance Scale",
            info="Controls the amount of guidance the text prompt guides the image generation",
    ),
    gr.Slider(
        minimum=0.5,
        maximum=2.5,
        step=0.01,
        value=1.5,
        label="Controlnet Conditioning Scale",
        info="""Controls the readability/creativity of the QR code.
        High values: The generated QR code will be more readable.
        Low values: The generated QR code will be more creative.
        """,
    ),
    gr.Slider(label="Steps", step=1, value=5, minimum=1, maximum=50),
    ],
    outputs=["image"],
    examples=[
        [
            "Hi OpenVINO",
            "cozy town on snowy mountain slope 8k",
            "blurry unreal occluded",
            42,
            7.7,
            1.4,
            25,
        ],
    ],
)
try:
    demo.queue().launch(debug=False)
except Exception:
    demo.queue().launch(share=True, debug=False)

# リモートで起動する場合は、server_name と server_port を指定
# 例: `demo.launch(server_name='your server name', server_port='server port in int')`
# 詳細については、Gradio のドキュメントを参照してください: https://gradio.app/docs/
